It would seem that the iron wheels in tractors are a relic of the past … Nothing could be further from the truth, in one of the Dutch farms this solution improves the tractor’s tractive power when working on very heavy, clay soil.
Installing wider tires , using twin wheels, releasing the pressure from the wheels, or adding additional weight to the tractor . There are many ways to improve the traction power of a tractor , and one of the more unconventional ways is successfully used on a farm in the Netherlands.
How to improve the tractive power of an agricultural tractor?
The Dutch family farm Enthoven in Zeewolde works on very heavy clay soils. In order to improve the traction of the tractor , the farmers themselves constructed a modern version of the additional metal wheels.
These wheels are equipped with 10 metal blades, which can be adjusted in length, which makes it possible to work at various working depths. As a result, when working in really difficult conditions, the 270 HP New Holland T7.270 towing the 7-furrow Lemken plow has a wheel slip of only 0-1%.
This solution primarily improves traction, but also reduces fuel consumption. It is also worth noting that the additional metal wheels increase the width of the tractor very little , which is especially important when plowing or driving on public roads.
Thanks to the adjustable length of the metal blades, also wheeled transport is not a problem, because the blades can be hidden so much that they do not protrude beyond the outline of the tires.
Interestingly, this system has been used on the farm for five years and so far farmers have had no problems with it.
In the video below you will see how the metal wheels perform in practice.
And what unusual ways to improve traction do you use in your tractors ? Be sure to let me know in the comments!
